Pendennis introduces new Digital Manufacturing Centre in Falmouth
At Pendennis we’re always looking to improve our facilities and services, and our most recent technological development has been the opening of a new Digital Manufacturing Centre (DMC) on-site in Falmouth. The DMC extends our current capability with additional CNC cutting, profiling and machining equipment to fully leverage our existing 3D scanning and design capability. We can offer machining services in-house and extend our services to local companies.
On-site we have a CNC water cutting machine capable of cutting almost any material 200mm thick, 4 metres long by 2 metres wide. We can also tap holes and mark parts if required.
We also have a CNC VMC Machine (Vertical Milling Centre) which has a capacity of 1100mm x 610mm x 610mm and is programmed from 3D CAD CAM software (Computer aided Design) (Computer aided Manufacturing). Our CNC Turning capacity is 1 metre long by 350mm diameter.
If you’re interested in finding out more about our services, for water cutting enquiries you can email waterjet@pendennis.com or for machining enquiries email machineshop@pendennis.com
Full list of Pendennis' Digital Manufacturing Centre Machinery with specifications:
XYZ TC400 (CNC Lathe)
- Spindle Bore: 91mm
- Maximum Turned Length – 600mm
- X - Travel – 265mm
- Z - Travel – 650mm
- Spindle Speed – 3,300rpm
- Maximum Swing – 600mm
XYZ SLX 555 (CNC Lathe)
- Swing over bed – 560mm
- X - Travel - 280mm
- Z – Travel - 900mm
- Distance between centres – 1000mm
- Max cutting length – 1000mm
- Spindle bore – 104mm
- Spindle speeds – 30-1800rpm (2 speed ranges)
- Maximum Swing – 560mm
XYZ VMC 1100 HD (CNC Milling Machine)
- Table load capacity – 1500Kg
- Table size – 1200x600mm
- X Travel – 1100mm
- Y Travel – 610mm
- Spindle to Table – 150-760mm
- Through Spindle High Pressure Flood Coolant.
- 30 Station Arm Type tool changer
XYZ SMX 4000 (CNC Milling Machine)
- Table load capacity – 850Kg
- Table size – 1474x355mm
- X - Travel – 1016
- Y - Travel – 596
- Z - Travel – 520
WJS Waterjet (CNC Water Cutting Machine)
- Table load capacity – 9600Kg
- Cutting area – 4000x2000
- X - Travel – 4010mm
- Y - Travel – 2010mm
- Z - Travel – 250mm
- 90’000 PSI / 6200 BAR
- Accuracy 0.05mm
